Osmoseur Slim 4" Pro for cloudy water
Osmoseur Slim 4" Pro for cloudy water
Osmoseur Slim 4" Pro for cloudy water

Slim 4" Osmosis Unit Pro for your well or borehole – brackish water special

The Osmosiser SLIM 4″ PRO for cloudy water Eliminates salt, viruses, bacteria, PFASs, and the eternal pollutants from your well or borehole water.

  • ✓Until 200 liters per hour, That is 4,800 liters per day
  • ✓For raw water up to 10,000 ppm from TDS
  • ✓Components in stainless steel, Stable operation up to 25 bars

Ideal for coastal installations (houses, chalets, hotels) and small industrial applications.

From: 11 800,00€ HT

Image optional consumables Quantité :
Big Blue 20-inch filter holder

Porte-Filtre 20 " pour forte teneur en sédiments

This 20-inch filter housing offers great versatility to meet all your high-capacity filtration needs, especially for high-flow or high-sediment applications. It is an ideal complement to the SLIM 4" PRO osmometer for your well or borehole. Although the osmometer already includes a small 10-inch sediment filter, this 20-inch additional filter will help extend the lifespan of your Professional Osmosis System membrane.
1
20-inch sediment cartridge for Big Blue filter holder

Cartouche 20" fibre tissée 25 microns pour sédiments

The very large holding capacity of this 20-inch sediment cartridge extends its lifespan. It is made of 25 Microns woven fibers.

No microfiber migration in the water, ideal for filtering sediments upstream of your professional Osmosis unit
1
Categories , Tag Product ID: 4189

Description

PROFESSIONAL OSMOSIS FOR SALTY WATER

Slim 4″ Pro brackish water: desalinate the water from your well

This reverse osmosis system filters the water from your well or borehole in a simple and efficient way: it removes salt, viruses, bacteria, PFASs and forever pollutants.

A reliable and compact solution for waters up to 10,000 ppm TDS.

200 L/h

either 4,800 liters per day

10,000 PPM

Maximum TDS for raw water

25 bars

Stable operation, all stainless steel

24 months

of guarantee

What the brackish water osmoser removes

Reverse osmosis eliminates dissolved salts, bacteria and viruses, chlorine, nitrates and heavy metals. The taste, smell and transparency of the water are improved.

SaltVirusBacteriaPFASNitratesHeavy metals

Designed to last

All components in contact with water are made of stainless steel resistant to corrosion, with a seamless piping system for stable operation up to 25 bars. High-pressure pump Grundfos CRN 1-30 and membrane FilmTec LCLE PRO-4040.

For whom?

An optimal choice for the Coastal installations : individual houses, chalets, hotels.

It is also suitable for Small industrial applications Cosmetics, automotive maintenance products, household chemicals, distillates, laboratory water.

Its controller allows for one online access and real-time monitoring: flow rates, water quality, and operational status.

Contact us

How does it work?

  1. PreprocessingFiltration of the sediment to protect the membrane.
  2. High-pressure reverse osmosisThe semi-permeable membrane only allows water molecules to pass through: salts and contaminants are retained.
  3. Concentrated rejectionThe brine is being evacuated.
  4. Produced waterStorage in your tank or direct use.

Technical specifications

FeaturesValues
Filtration typeReverse osmosis for fairly muddy water
Max filtration200 liters/hour or 4800 liters/day
Service pressure15-20 bars
Input pressure2-4 bar
Recovery rates75 %
Membrane capacity2400 GPD (Gallons per Day)
Type of membraneFilmTec™ LCLE PRO-4040 4″
Number of cartridges1 membrane + 1 sediment filter
Dimensions (L*W*H)364*289*1480
Diameter of water supply1/2 inch
Electrical power1.6 kW
Maximum TDS of your raw water10,000 PPM
PumpHigh pressure Grundfos® CRN 1-30
CertificationCE, NSF 58
Power supply230 V 50 Hz single-phase
Pre-filter for sediment 5 μm Yes
24-month warranty Yes
In Stock Yes
Here are the official French instructions and the technical brochure, which you can download by clicking on the links below:


Slim 4″ 6500 PRO Brackish Water Brochure in French

Slim 4″ 6500 Pro Brackish Water User Manual in French

Your osmoseur Slim 4″ Pro grey water is supplied with:

  • Pump Grundfos® CRN 1-30
  • Membrane tank 450 psi
  • A 10″ sediment pre-filter
  • Electrical panel with controller OC6500
  • Tubes and instrumentation
  • Steel frame
  • A float to automatically cut off the filtration when your tank is full

We also recommend equipping your pump with a pressure gauge, so that it cuts off automatically as soon as the osmoseur is switched off.
